The Verlichte Rockerschakelaar combines functionality and visual appeal with its integrated orange LED illumination. This 12 V switch ensures clear operational status visibility, even in low-light conditions. With its robust 2P DPST configuration, it efficiently handles dual circuit controls, providing reliable on-off switching.
Designed to accommodate a wide range of appliances, this switch is versatile for various electrical applications. The intuitive rocker mechanism simplifies operation, while its sturdy construction promises longevity. Perfect for projects requiring dependable on-off capabilities and a visual cue, ensuring both performance and aesthetic value.
| Brand | SCI |
| Model | R13244BY/LED |
| Lighting | orange LED (12 V 10 mA) |
| Dielectric strength | 1500Vac / 1 minute |
| Housing | 66 nylon (UL94V-2) |
| Insulation resistance | At least 100MΩ at 500Vdc |
| Contact | 16 A / 12 VDC |
| Electric lifespan | 20,000 cycles |
| Contact resistance | "50 milliohm" |
| Connections | Silver-plated brass |
| Get in touch | Equipped with a spring |
| Mechanical lifespan | 50,000 cycles |
| Tuimelaarknop translates to "tumbler button" in English. | 66 nylon (UL94V-2) |
| Movable contacts | Silver-plated brass |
| Static contacts | Silver-plated brass |
