Sparkfun Raspberry Pi 5 - 2GB

The Raspberry Pi 5 - 2GB is a powerful single-board computer equipped with a 64-bit quad-core Arm Cortex-A76 processor clocked at 2.4GHz, offering a 2–3× boost in CPU performance compared to its predecessor. It features an 800MHz VideoCore VII GPU for enhanced graphics, dual 4Kp60 HDMI display outputs, and advanced camera support through a redesigned Image Signal Processor. This iteration is the first to include silicon developed in-house, with the RP1 "southbridge" significantly enhancing I/O capabilities and peripheral performance. The device includes 2GB of LPDDR4X-4267 SDRAM.

Perfect for both consumers and industrial applications, this version ensures a seamless desktop experience and expands possibilities for creative and technical projects. Whether you're developing complex simulations, running media centers, or implementing IoT solutions, the enhanced processing power and graphics capabilities make it an ideal choice.

Unique features like the doubled aggregate USB bandwidth facilitate faster data transfers to external drives and high-speed peripherals. The new four-lane 1.5Gbps MIPI transceivers replace the older two-lane interfaces, tripling the total bandwidth and supporting up to two cameras or displays simultaneously. This opens up new opportunities for multimedia projects and surveillance systems.

Additionally, the platform's support for the SDR104 high-speed mode doubles the peak SD card performance, ensuring rapid data access and storage. The introduction of a single-lane PCI Express 2.0 interface allows for the integration of high-bandwidth peripherals, further expanding the device's versatility and potential applications.
