Gainta Impact-Resistant Polycarbonate Enclosure with Neoprene Seal
New
Description
The enclosure crafted from impact-resistant polycarbonate ensures durability in extreme conditions, ranging from -40°C to +125°C. Its light gray hue complements a variety of settings.
The innovative cover and baseplate come with a tongue and groove system featuring a neoprene seal. This design ensures openings for wall and cover screw mounting are outside the sealed area, preventing the ingress of dust and moisture.
Internal slots facilitate vertical PCB mounting, adhering to IP65 and NAMA4 standards for dust and splash protection. Brass threaded inserts in the base offer options for horizontal PCB mounting and connector installation, enhancing versatility.
Properties
Brand information
| Brand | Gainta |
| Model | G203 |
Other
| Primary colors | Gray |
| Depth of the product | "65 mm" |
| Height of the product | 40 mm |
| Width of the product | 115 mm |
| Weight Product | The number 114 grams doesn't require translation as it is already in English. If you're referring to something else by "114 g," please provide additional context. |
| Place of use | Only indoors |
| It looks like you've provided the phrase "Type montage" for translation into English, but it already appears to be in English. Could you please provide more context or text for translation? | Detached |
| Lid | Yes |
| Primary detailed colors | Light gray |
| Maximum operating temperature | 125°C |
| Minimum operating temperature | -40 °C |
| Sealed. | Yes |
| DIN-rail | no |
| Confirmations | no |
| "Flirting" | no |
| With little feet | no |
| Montagegaten translates to "Assembly Street" in English. | Yes |
Datasheet
| Material | Polycarbonate/UV-stabilized |
€ 13,30€ 11,00 Excl. VAT (NL)
