Daily Well Digitast DIP Push Button Switch with LED Illumination
New
Description
The Digitast DIP push button switch features a distinctive blue cover and integrated red LED illumination for dynamic function displays. This tactile switch offers a crisp click feedback, ensuring reliable operation in compact electronic designs.
Specifications:
- Rated Voltage: 30V DC
- Contact Resistance: 100 mΩ max
- Insulation Resistance: 100 MΩ at 500V DC
- Operating Temperature: -30°C to +85°C
With its user-friendly design, it suits a range of applications from home automation to intricate PCB assemblies. Ideal for settings where immediate visual feedback and precision are necessary—just like the dependable buttons on high-end control panels.
Properties
Brand information
| Brand | Daily Well |
| Model | 86A271C |
Other
| Dielectric strength | 250Vac 1 minute (except between LED connections) |
| Insulation resistance | 100MOhm (250Vdc resistance meter) |
| Description | Blue digitast cap - red LED |
| Values | 5mA - 24Vdc (a minimum current of 1µA is acceptable) |
| Working temperature | -25°C to +75°C |
| Electric lifespan | 200,000 switchovers (at max voltage and current) |
| Contact resistance | Initially max. 20mohm (AC 200µV, 5mA) |
| Static power | 1.5pF max. (1MHz) |
| "Gear resistance" | 30G (3 directions perpendicular to each other, 3x) |
€ 4,70€ 3,90 Excl. VAT (NL)
