Daily Well Vertical Toggle Switch with DPDT Configuration
Description
This vertical toggle switch offers precise on-off control with its DPDT configuration, perfect for intricate circuit designs. Equipped with a momentary (ON) position, it seamlessly transitions between operations.
Reliable in various applications, from switching power sources to complex machinery controls. Its PCB mount type ensures secure installation, conserving space within compact electronic assemblies.
With a robust construction, it withstands continuous use, providing enduring performance. The intuitive toggle design delivers efficient user interaction similar to flipping a light switch, simplifying complex tasks.
Properties
Brand information
| Brand | Daily Well |
| Model | 8012BC |
Other
| Dielectric strength | 1000Vrms at sea level |
| Insulation resistance | Minimum 1000 megaohms. |
| Note | PCB type |
| Contact | 5A with a resistive load of 120Vac or 28Vdc |
| Working temperature | -30°C to +85°C |
| 2-3, 5-6 | ON |
| OPEN | OFF |
| 2-1, 5-4 | (ON) |
| Electric lifespan | 50,000 make-and-break cycles at maximum load |
| Contact resistance | Initially max. 10mohm at 2-4Vdc / 10mA for silver-plated and gold-plated contacts |
| Housing (materials) | Melamine of diallyl phthalate (DAP) |
| Steel | Chromed brass |
| The word "Schroefdraad" translates to "screw thread" in English. | Nickeled brass |
| Frame | Stainless steel |
| Contacts (materials) | cashed in |
| Connections | Silver-plated brass |
| The term "Middencontact" can be informally translated to "center contact" or "middle contact." However, if there's a specific context or additional meaning, please let me know! | Silver-plated brass |
€ 2,80€ 2,35 Excl. VAT (NL)
