Velleman 4P Connector with IP68 Certification for Outdoor and Industrial Use

Item number CUI04 Brand Velleman Model CUI04  Share Write a review

New

Velleman 4P Connector with IP68 Certification for Outdoor and Industrial Use

Description

The 4P Connector is meticulously engineered to offer seamless connectivity. With water-resistant IP68 certification, it guarantees robust performance in challenging environments, making it ideal for outdoor LED lamps, LED displays, and servomotors.

Capable of supporting 16A at 230V, it provides reliable electrical flow for applications including machine tools, control measurements, process technology, and medical equipment. Its durable build ensures longevity, similar to a dependable bridge across a bustling river.

Properties

Brand information

Brand	Velleman
Model	CUI04

Other

Number of Contacts	4
Insulation resistance	> 100 MOhm
Working temperature	-40 to 95 °C
Contact resistance	Less than 5 mOhm
Wire diameter	0.5 - 2.5 mm²
Inner cable connection	Screw connection
"Nom. spanning" translates to "Don't worry" in English.	Maximum 320 V
Nominal current	16 A @ 55 °C
Mechanical action	Over 200 connection cycles
IP protection grade	IP68 (when connected)
For cable diameter	Between 5 and 7.4 mm
Flammability	UL94-V2 is a classification for a certain level of flame retardancy for plastic materials.
