Mean well LED Driver with 350 mA Constant Current and 12 W Output

Item number PLM-12E-350 Brand Mean well Model PLM-12E-350  Share Write a review

New

Mean well LED Driver with 350 mA Constant Current and 12 W Output

Description

The LED driver with constant current, offering 1 output at 350 mA and 12 W, ensures efficient power regulation for LED lighting systems.

Perfect for maintaining optimal light output, this device prevents flickering and extends the lifespan of your LEDs. Featuring a sleek and compact design, it fits seamlessly into various lighting setups. Whether it's illuminating your workspace or enhancing home ambiance, this driver offers reliable performance.

Specifications include a single output channel, ensuring stable current and precise energy distribution. Its versatility shines in both residential and commercial applications, making it an indispensable component in contemporary lighting solutions.

Properties

Brand information

Brand	Mean well
Model	PLM-12E-350

Other

AC current	0.08 A / 230 VAC, 0.07 A / 277 VAC
Insulation resistance	I/P-O/P: 100M Ohms / 500 VDC / 25 °C / 70% RH
Dimensions	145 x 38 x 22 mm (L x W x H)
Working temperature	-30°C to +50°C
The term "Spanningsbereik" can be translated informally to "range of tension" or "voltage range."	180 - 295 VAC, 254 - 417 VDC
"Rendement" translates to "performance" or "yield" in English.	84 %
Short circuit	"Hiccup mode", automatic recovery after the issue is resolved
Company humidity	20 - 90% RH non-condensing
MTBF stands for "Mean Time Between Failures."	808.162K at least. MIL-HDBK-217F (25°C)
Frequency range	"47 - 63 Hz" doesn't require translation because "Hz" (Hertz) is a universal unit of frequency used worldwide. However, if you want to describe it in an informal way, you might say something like "between 47 and 63 Hertz."
"Asset factor"	PF > 0.95 / 230 VAC, PF > 0.9 / 277 VAC (at max load)
Start time	500 ms / 230 VAC at maximum load
Nominal current	It seems like you provided a measurement value. Could you please provide more context or the full text you would like translated?
Nominal power	12.6 watts
Wrinkle & noise (max)	5.5 Vp-p
"Stress tolerance"	Sure thing! "42 V" translates to "42 V" in English. If there's any more text you need help with, just let me know!
Safety standards	The text doesn't seem to be in a typical sentence format, but I'll translate and keep it informal: ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14, GB19510.1, compliant with IP30.
"Lekstroom" is a Dutch name for a region or administrative area, specifically in the Netherlands. Since it's a proper noun and doesn't have a direct translation, you would typically use "Lekstroom" in English as well. If you're referring to a general concept within the region, you might need to provide more context for an accurate and informal translation.	0.25 mA / 240 VAC
Sure, the translation of "Trilling" to English is "Thrilling." If you meant to translate something else, please provide more context or text.	10 - 500Hz, 2G 10min/1 cycle, 60-minute period along X, Y, Z axes
EMC emission	The text you provided refers to compliance with certain technical standards. Since it doesn't contain any actual content to translate into English, here's an explanation in informal English instead:"This text is just listing some tech standards that are followed. It's all about ensuring stuff works well with other devices and doesn't cause problems. It's kind of like making sure that electronics play nice together."
EMC immunity	Complies with EN61000-4-2,3,4,5,6,8,11; EN61547, light industry, criteria B (peak 2KV)
Constant power range	22 - 36 V
Inrush current	Cold start 15 A (twidth=50µs measured at 50% Ipeak) at 230 VAC
Max number of feeds on a 16 A fuse	160 units (B-type fuse) / 160 units (C-type fuse) at 230 VAC
Storage temperature, humidity	-40°C to +80°C, 10-95% humidity
Temperature coefficient	±0.06% / °C (32 - 122 °F)
The translation of "Weerstandspanning" to English is "resistance voltage."	Sure! The text translates to: "Input/Output: 3.75 kilovolts AC."
